25KG AB PUR Potting Compound Black Thermally Conductive Adhesive

Name: 25KG AB PUR Potting Compound Black Thermally Conductive Adhesive
Brand: DongGuan Ancham New Material Technologies Co.，Ltd.
SKU: AP83(50)
Availability: InStock

Brand Name:	Ancham
Model Number:	AP83(50)
MOQ:	120KG
Price:	NA
Payment Terms:	T/T
Supply Ability:	50000kg/month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

RoHS Reach

Mixing Weight Ratio:

5:1

Viscosity:

1100±300 MPa.s

Hardness:

50±5 Shore D

Dielectric Strength:

≥20 KV/mm

Type:

Electronic Adhesive

Country Of Origin:

China

Packaging Details:

25kg:5kg

Supply Ability:

50000kg/month

Highlight:

25KG Potting Compound

AB Potting Compound

Thermally Conductive Adhesive

Product Description

25KG AB Black Thermally Conductive Electronic Polyurethane Potting Compound

FEATURES

1. Solvent free.

2. Good flowability.

3. Excellent adhesion.

4. Excellent water resistance and environmental aging resistance.

5. Comply with RoHS and Reach.

APPLICATIONS

1. Potting of capacitors, wire harnesses, connectors, circuit boards.

2. Potting protection for transformers, instrumentation, ignition controllers, sensors.

3. motor motor, power tool control module, power module insulation protection.

TECHNICAL DATA

TYPICAL PROPERTIES	AP83(50)
Mixing Ratio @ 25℃	5:1
Appearance	Black
Viscosity @ 25℃	1100±300 mPa.s
Specific Gravity @ 25℃	1.45±0.05 g/cm^3
Cure Schedule @ 150g	Initial cure time 9~15h @ 25˚C / 0.5~1h @ 80℃ Full cure time 168h @ 25℃
Hardness	50±5 Shore D
Lap Shear Strength @ 25℃	7 Mpa ABS/ABS
Useful Temperature Ranges	-40~150℃
Dielectric Strength	≥20 kV/mm
Volume Resistivity	3.6x10^13 Ω.cm
Shelf Life (15~25℃)	6 months

1. Two-Component Formulation
This potting compound is a two-component polyurethane system designed specifically for thermal conductivity and effective insulation.

2. Superior Adhesion
It provides excellent adhesion to a wide range of substrates, including most plastics, metals, and glass, ensuring a strong and reliable bond for electronic components.

3. Stress-Sensitive Protection
Ideal for the insulation protection of stress-sensitive electronic components, this compound helps shield devices from mechanical impacts and stresses.

4. Excellent Chemical Resistance
The formulation boasts outstanding chemical resistance, making it suitable for use in harsh environments, ensuring long-term durability.

5. Low Dielectric Constants
AP83(50) maintains low and stable dielectric constants across a broad temperature range, enhancing its effectiveness in various electronic applications.

FAQ

1. who are we?
We are based in Guangdong, China, start from 2002,sell to Domestic Market(82.00%),Southeast Asia(10.00%),North
America(4.00%),South America(1.20%),Eastern Europe(1.00%),Mid East(0.80%),Western Europe(0.50%),Southern Europe(0.50%). There are
total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Epoxy/Polyurethane/Acrylic Adhesive,Silicone Sealant,Potting Compound,Thermally Conductive adhesive,Conformal Coating
4. why should you buy from us not from other suppliers?
Ancham's electronic adhesive products involve epoxy resins, acrylates, urethanes, and silicones, covering bonding, sealing,
thermal management, potting, and coating protection. 100+ Testing equipment 150+ Proven Products 3500 Tons annual capacity
