Pink Electronic Potting Silicone Compound Thermal Conductive For Electronics

Brand Name:	Ancham
Model Number:	AS42(35)
MOQ:	100kg
Price:	NA
Payment Terms:	T/T
Supply Ability:	50000kg/month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

UL94-V0 RoHS REACH

Thermal Conductivity:

3.8±0.1 W/m-K

Viscosity @ 25℃:

12500±2500 MPa.s

Specific Gravity @ 25℃:

3.0±0.1 G/cm^3

Hardness:

25±5 Shore A

Type:

Electronic Adhesive

Country Of Origin:

China

Packaging Details:

25kg

Supply Ability:

50000kg/month

Highlight:

Pink potting materials 12500mPa.s

potting silicone 25000g

Pink silicone potting compound for electronics

Product Description

25KG Pink Electronic Thermal Conductive Silicone Potting Compound

DESCRIPTION

1. Two-Component System
This silicone potting compound consists of two components, ensuring a reliable and effective thermal management solution for electronic applications.

2. Low Viscosity
Featuring low viscosity, the compound easily flows into small gaps and intricate designs, providing comprehensive coverage and protection for components.

3. Low Stress Characteristics
Designed to minimize mechanical stress, this potting compound safeguards sensitive electronic devices from potential damage during operation and environmental changes.

4. Excellent Flowability
With its superior flowability, this silicone compound is ideal for potting capacitors, transformers, and other complex electrical components, ensuring effective application.

5. High Thermal Conductivity
Boasting a thermal conductivity of 3.8 W/m·K, it meets the high thermal management and insulation needs of power adapters and various electronic devices, facilitating efficient heat dissipation.

FEATURES

1. Thermal conductivity 3.8W/m·K.

2. Low stress.

3. Excellent environmental aging resistance, high and low temperature resistance.

4. Flame retardancy in accordance with UL94-V0.

5. RoHS, REACH compliant, halogen free.

APPLICATIONS

1. Potting applications with high thermal conductivity and insulation requirements such as hydrology, weather sensors, power modules, power supply modules, headlight modules, OBCs, DC-DC modules, etc.

TECHNICAL DATA

TYPICAL PROPERTIES	AS42(35)
Mixing Ratio @ 25℃	1:1
Appearance	Pink
Viscosity @ 25℃	12500±2500 mPa.s
Specific Gravity @ 25℃	3.0±0.1 g/cm^3
Cure Schedule @ 2cm	Initial cure 3~5h @ 25℃ Full cure 24h @ 25℃ Full cure 20~30min @ 80℃
Hardness	25±5 Shore A
Thermal Conductivity	3.8±0.1 W/m·K
Useful Temperature Ranges	-50~200℃
Dielectric Strength	≥10 kV/mm
Volume Resistivity	2.89x10^12 Ω.cm
Shelf Life (8~28℃)	6 months
